To connect your PAX A35 terminal to a Wi-Fi network, follow these steps:

1. On the terminal’s main screen, touch the Settings icon.
2. On the Settings screen, touch the Please Input Password field and use the keypad to type the password: `pax9876@@`.
3. Touch the checkmark icon on the keypad when you are done and touch OK.
4. On the Settings page, touch Network & Internet.
5. On the Network & Internet page, touch Wi-Fi.
6. If Wi-Fi is Off, touch the toggle to turn it on. If Wi-Fi is already on, a list of available networks appears.
7. From the list of available networks, touch the name of the network you want to connect to.
8. Enter the password for the selected network and touch CONNECT.
9. After the terminal displays connected to the selected network, touch the Back icon to return to the Network & Internet page.

To connect the PAX A35 to an Ethernet network, follow these steps:

1. Ensure your network cable is connected in the appropriate connector located on the back of the terminal and make sure the other end of the network cable is connected to a network jack or hub.
2. On the terminal’s main screen, touch the Settings icon.
3. On the Settings screen, touch the Please Input Password field and use the keypad to type the password: either 9876 or pax9876@@.
4. Touch the checkmark icon on the keypad when you are done and touch OK.
5. In the Wireless & networks section, touch Ethernet.
6. If Ethernet is Off, touch the toggle to turn it on.
7. After you toggle Ethernet to On (or if Ethernet is already on), the connected network settings appear.
8. If necessary, you can change the network connection parameters manually by scrolling to the bottom and touching Ethernet Configuration to select and configure the Connection Type.

IMPORTANT! Changing the network connection parameters incorrectly will prevent the terminal from communicating with the payment processing server.

To power off the PAX A35 terminal, press and hold the red X key on the physical keypad.
